Fire-Rated Windows

Transparent fire protection from 20 minutes to 2 hours. ASTM E119 certified fire-rated glass and framing systems by SAFTI FIRST. Fixed, casement, awning, hopper, and vision panel configurations. Blocks smoke, flames, and radiant heat. Interior and exterior rated.

Contact us
Home
/
Products
/
Fire-Rated Windows

Advantages

check icon
20-Minute to 2-Hour Fire Ratings
check icon
Fire Protective & Fire Resistive Options
check icon
Multiple Window Configurations Available
check icon
Clearest Fire-Rated Glass Available
check icon
Blocks Smoke, Flames & Radiant Heat
check icon
ASTM E119/UL 263 Certified
check icon
GPX Aluminum Framing Systems
check icon
Made in USA by SAFTI FIRST

Certificates

No items found.

Product Benefits

FOR ARCHITECTS
Maximum transparency with code compliance, storefront-like appearance, NFRC-certified for energy performance, design flexibility with custom finishes and daylighting without compromising fire protection.
FOR CODE OFFICIALS
UL/Intertek-listed and labeled assemblies, meet IBC wall opening requirements, ASTM E119/NFPA 257 compliant, proper glazing markings, fire resistive vs fire protective clearly identified.
FOR CONTRACTORS
Factory-assembled systems ready to install, complete installation packages, fast lead times from California manufacturing, technical support throughout project, submittal packages included
FOR BUILDING OWNERS
Life safety compliance with enhanced aesthetics, natural daylighting reduces energy costs, transparent fire barriers create open environments, and enhance property value, with low maintenance.

Technical Details

20-120 MINUTE FIRE RATINGS
Fire protective (20-45 min) or fire resistive (45-120 min). ASTM E119/NFPA 257 tested and certified.
MAXIMUM SIZES UP TO 96" × 96"
Sizes vary by fire rating and configuration. Larger sizes available with butt-glazed assemblies.
MULTIPLE CONFIGURATIONS
Fixed, casement, awning, hopper windows. Vision panels, sidelights, transoms, borrowed lites.
GPX FRAMING SYSTEMS
Aluminum or hollow metal frames. 2-1/2" equal sightlines. Storefront appearance. Multiple finish options.
FIRE PROTECTIVE GLASS
SuperClear 45-HS, SuperLite I-XL, Ceramics. Blocks smoke and flames. 20-45 minute ratings.
FIRE RESISTIVE GLASS
SuperLite II-XL 45/60/90/120. Blocks smoke, flames AND radiant heat. Required for walls >25% glazing.
INTERIOR & EXTERIOR RATED
Interior standard. Exterior with insulated units and proper detailing. NFRC energy-certified options.
CUSTOM FINISHES AVAILABLE
Clear anodized, bronze anodized, black anodized, painted, wood veneer, and ornamental metal. Custom colors available.

Performance

20-45 MINUTE FIRE PROTECTIVE
Blocks smoke and flames. Tested to NFPA 257/UL 9/10C. Most economical option for small openings.
45-120 MINUTE FIRE RESISTIVE
Blocks smoke, flames and radiant heat. ASTM E119/UL 263 tested. Required for walls >25% glazing.
BUTT-GLAZED WALLS
Frameless appearance with SuperLite II-XLM or II-XLB. 60-120 minute ratings. Maximum transparency.
HOSE STREAM TESTED
All fire-resistant products pass hose stream test. Ensures integrity after fire exposure and water application.
IMPACT SAFETY RATED
CPSC 16 CFR 1201 Cat. I and II. ANSI Z97.1 compliant. Safe for all hazardous locations.
SOUND CONTROL
STC ratings 37-44 depending on configuration. Quiet environments. Healthcare, educational applications.
ENERGY PERFORMANCE
NFRC certified when insulated. Low-E options available. U-Factor and SHGC compliance for exterior applications.
LEED CERTIFIED
LEED-compliant materials. Made in the USA for regional materials credit. Sustainable manufacturing.
